Internal combustion battery…sort of

The center section is essentially 2 combustion chambers back to back, the orange wrap is the ‘stator’ of an electric generator. When the magnets tied to the piston runs through the stator it generates electricity. Then a spring returns the stator to the center and the cycle (2 cycle) starts again.
Green Car Report :Could Free Piston Range Extenders Broaden the Electric Truck Horizon?
One of the ‘cool’ things about a Free Piston Engine is that it can be packaged in a fairly simple block and because of the elimination of the mechanical drive train and residual mechanical controls (valves, cams, etc) the machine can eat different types of fuel and be tuned in a wide variety of ways quite simply. This makes it compatible with battery electric systems on a packaging and mission program ability standpoint.
A simple schematic of the bare bones of a free piston machine. Other uses have been proposed but tying it to a generator and modern power electronics to make it a range extender is pretty interesting. The technology is derivative of the highly refined IC engines of today and the equally long history of electric generators so this should be something that matures pretty quickly.
